Saw diameter

700 mm

...........................................................................................................................................................................................

Number of calibrating / Polishing heads

3 / 12

...........................................................................................................................................................................................

Diameter of calibrating/polishing disc

700 - 500 mm.

...........................................................................................................................................................................................

Max. Working thickness

60 mm.

...........................................................................................................................................................................................

Belt width

900 mm.

...........................................................................................................................................................................................

Calibrating engine power

22 Kw. 1000 d/dk

...........................................................................................................................................................................................

Polishing engine power

11 Kw. 1000 d/dk

...........................................................................................................................................................................................

Drying fan

3 Kw.

...........................................................................................................................................................................................

Belt Gear Box

1,5 Kw.

...........................................................................................................................................................................................

Bridge movement engine

1,5 Kw. 1400 d/dk With Engine Brake (2 x)

...........................................................................................................................................................................................

Total engine power

207 Kw.

...........................................................................................................................................................................................

Machine dimensions

14000 x 2000 x 2000 mm.

...........................................................................................................................................................................................

Max. Water expenditure

300 Lt/dk

...........................................................................................................................................................................................

Total machine weight

19200 Kg.

...........................................................................................................................................................................................

Working System

See the all system on touch screen panel with PLC controller, working automatically and manually
