PLAKA DEVİRME
ÜRÜN DETAYLARI - TEKNİK ÖZELLİKLER
İlerleme kurs boyu
2000 mm
...........................................................................................................................................................................................
Devirme açısı
95 °
...........................................................................................................................................................................................
Çalışma sistemi
hidrolik sistem
...........................................................................................................................................................................................
Hidrolik sistem motor gücü
2.2kw 1500d/dk
...........................................................................................................................................................................................
Rulo tahrik motor gücü
0.75 kw 900 d/dk
...........................................................................................................................................................................................
İleri geri tahrik motor gücü
1.5 kw 1400 d/dk
...........................................................................................................................................................................................
Toplam elektrik gücü
4 .5 kw
...........................................................................................................................................................................................
Vakum ped çapı ve sayısı
Ø260 18 adet
...........................................................................................................................................................................................
Plaka alma sistemi
Pnömatik vakum
...........................................................................................................................................................................................
Makine ebatları
3200x2300x800
...........................................................................................................................................................................................
Makine ağırlığı
1800 kg
...........................................................................................................................................................................................
...........................................................................................................................................................................................
Çalışma özelliği
PLC kontrollü tam otomatik veya yarı otomatik olarak çalışabilme
