Ana motor gücü

110 kw . 1500 d./dk

...........................................................................................................................................................................................

Kesim hız motor gücü

11 kw . 1500 d/dk

...........................................................................................................................................................................................

Lama adedi

80 Adet

...........................................................................................................................................................................................

Kesim strok sayısı

96 d./dk

...........................................................................................................................................................................................

Blok kesim ölçüleri

Max 3300x2000x2100 mm

...........................................................................................................................................................................................

Kalınlık kesim ölçüleri

Min.16 mm.-max. Serbest

...........................................................................................................................................................................................

Blok araba

2 x 1.5 kw . 1400 d./dk

...........................................................................................................................................................................................

Transfer Arabası

1 x 1.5 kw. 1400 d./dk

...........................................................................................................................................................................................

Çalışma Özelliği

Beşik kollu

...........................................................................................................................................................................................

Kesim Şekli

Asansör sistemi(Blok yukarı kaldırılarak)

Asansör Tahriği

4 noktada modüler dişli kutusu ve dönüşü

manyetik sensörlerle kontrol edilen vidalı miller ile

...........................................................................................................................................................................................

Blok Emniyet ve plaka kırılmalarda lazer switch

Standart

...........................................................................................................................................................................................

Montaj Alanı

4340x12825x4885 mm

...........................................................................................................................................................................................

Max. Su ihtiyacı

800 lt./dk

...........................................................................................................................................................................................

Makine emniyetleri

Volant + v kollari , vagon yukarı-aşağı

...........................................................................................................................................................................................

Genel kontrol

Plc sistemli

...........................................................................................................................................................................................

Acil kurtarma

Max. 30 sn. sürede komple hareketli durdurabilme

...........................................................................................................................................................................................

Arıza kontrol

18 noktadan vibrasyon ve limit kontrol mevcut arızayı tanıma

...........................................................................................................................................................................................

Makine Ekipmanları

2 adet blok ve 1 adet transfer arabası

...........................................................................................................................................................................................

Toplam ağırlık

55000 kg
